REAR SWINGING ARM- REAR SHOCK ABSORBER

ref

part #

description

quantity

1

4361011817
ref: 1

REAR FOOTREST ASS'Y

€ 153.50

2

4361211000
ref: 2

RUBBER,REAR FOOTREST

€ 153.50

3

6110011820019
ref: 3

REAR SWINGING ARM

€ 0.00

4

6121111002
ref: 4
O.D=12 (0.47) L=217 (8.54)

REAR SWINGING ARM PIVOT SHAFT

€ 37.00

5

6125109200
ref: 5

REAR SWINGING ARM PIVOT SHAFT SPACER

€ 29.50

6

6126209200
ref: 6

COVER,SWGARM BUSH DUST SEAL

€ 2.50

7

6131011600
ref: 7
CHROME PLATED

CHAIN CASE COMP.

€ 62.00

8

6210011600
ref: 8

ABSORBER ASSEMBLY,REAR SHOCK

€ 0.00

9

6221111602
ref: 9
O.D=50 (1.97) I.D=36 (1.42) L=203.5 (8.01) CHROME PLATED

SPRING

€ 31.50

10

6431011000
ref: 10

TORQUE LINK,REAR

€ 5.00

11

0910110003
ref: 11
O.D=10 (0.39) L=28 (1.10)

BOLT(10X31)

€ 4.00

12

0915912002
ref: 12

REAR SWINGING ARM PIVOT SHAFT NUT

€ 0.00

13

0916010001
ref: 13
O.D=24 (0.95) I.D=10.5 (0.41) T=2.3 (0.09)

WASHER

€ 2.00

14

0928024001
ref: 14
O.D=30 (1.20) I.D=24.5 (0.96) T=3 (0.12)

O RING(D:2,ID:24.5)

€ 2.00

15

0930118001
ref: 15

BUSHING

€ 10.50

16

0938510001
ref: 16

CLIP

€ 1.50

17

0944018002
ref: 17

SPRING

€ 1.50

18

0111106121
ref: 18

HEXAGON BOLT

€ 2.00

19

0212105121
ref: 19

CROSS HEAD SCREW

€ 1.00

20

0831111101
ref: 20

HEXAGON NUT

€ 2.50

21

0831231101
ref: 21

SMALL HEXAGON NUT

€ 2.50

22

0831311102
ref: 22

CROWN NUT

€ 2.50

23

0832121061
ref: 23

LOCK WASHER

€ 2.50

24

0832121101
ref: 24

LOCK WASHER

€ 2.00

25

0832211121
ref: 25

SMALL FLAT WASHER

€ 2.00

26

0832221051
ref: 26

FLAT WASHER

€ 2.50

27

0832331051
ref: 27

TOOTHED LOCK WASHER

€ 1.50
