TRANSMISSION-DRIVE CHAIN

ref

part #

description

quantity

1

2412111000
ref: 1
N.T=14

COUNTERSHAFT

€ 55.50

2

2413111000
ref: 2
N.T=22

DRIVE SHAFT

€ 88.00

3

2422111000
ref: 3
N.T=19

SECOND PINION

€ 40.00

4

2423111000
ref: 4
N.T=22

THIRD PINION

€ 0.00

5

2424111001
ref: 5
N.T=25

FORTH PINION

€ 27.50

6

2425111000
ref: 6
N.T=27

FIFTH PINION

€ 38.00

7

2426111000
ref: 7
N.T=28

TOP PINION

€ 33.50

8

2431111001
ref: 8
N.T=36

LOW GEAR

€ 0.00

9

2432011004
ref: 9
N.T=31

SECOND GEAR

€ 0.00

10

2433111000
ref: 10
N.T=28

THIRD GEAR

€ 0.00

11

2434111002
ref: 11
N.T=26

FORTH GEAR

€ 33.50

12

2435111000
ref: 12
N.T=24

5TH DRIVEN GEAR

€ 49.50

13

2474511040
ref: 13

COUNTERSHAFT BUSHING RETAINER

€ 4.00

14

2475111000
ref: 14

RETAINER,DRIVESHAFT

€ 4.50

15

2487111001
ref: 15

PLATE,OIL RESERVOIR

€ 6.00

16

2626011000
ref: 16
N.T=26

GEAR,KICK STARTER IDLE

€ 28.50

17

2628111000
ref: 17
N.T=24

GEAR,KICK STARTER DRIVE

€ 43.00

18

2751111000
ref: 18
STANDARD (#525,N.T=14)

ENGINE SPROCKET

€ 31.00

18

2751150760
ref: 18
OPTIONAL (#525,N.T=11)

ENGINE SPROCKET

€ 12.50

18

2751150761
ref: 18
OPTIONAL (#525,N.T=12)

ENGINE SPROCKET

€ 12.50

18

2751111700
ref: 18
OPTIONAL (#525,N.T=13)

ENGINE SPROCKET

€ 26.00

18

2751111710
ref: 18
OPTIONAL (#525,N.T=15)

ENGINE SPROCKET

€ 18.00

19

2760011600
ref: 19
INCLUDES REF.NO.20 #525TX96L

DRIVE CHAIN ASS'Y

€ 55.00

20

2762011610
ref: 20
#525T

CHAIN JOINT ASS'Y

€ 0.00

21

0914020001
ref: 21

NUT

€ 3.50

22

0916017001
ref: 22
O.D=29 (1.14) I.D=17 (0.67) T=1.0 (0.04)

WASHER

€ 3.00

23

0916017005
ref: 23
O.D=29 (1.14) I.D=17 (0.67) T=1.0 (0.04)

WASHER

€ 3.50

24

0916022003
ref: 24
O.D=34 (1.34) I.D=22 (0.87) T=1.0 (0.04)

SECOND GEAR INNER THRUST WASHER

€ 2.00

25

0916720006
ref: 25
O.D=37 (1.50) T=0.8 (0.03)

WASHER,LOCK

€ 3.00

26

0916722012
ref: 26
O.D=29 (1.14) T=1.0 (0.04)

WASHER,LOCK

€ 1.50

27

0916722002
ref: 27
O.D=34 (1.34) T=1.0 (0.04)

2ND DRIVEN GEAR OUTER THRUST W (TC250; O.D. =34(1.34), T =1.0(0.

€ 3.00

28

0918020003
ref: 28
O.D=25 (0.98) I.D=20 (0.79) W=14.4 (0.57)

ENGINE SPROCKET SPACER

€ 0.00

29

0926220003
ref: 29
O.D=52 (2.05) I.D=20 (0.79) W=15 (0.59)

BEARING(20X52X15)

€ 27.00

30

0926317001
ref: 30
O.D=21 (0.83) I.D=17 (0.67) W=12.8 (0.50)

BEARING(17X21X12.8)

€ 10.00

31

0926317004
ref: 31
O.D=21 (0.83) I.D=17 (0.67) W=9.8 (0.39)

BEARING(17X21X9.8)

€ 7.00

32

0928325002
ref: 32
O.D=52 (2.05) I.D=25 (0.98) W=7 (0.28)

SEAL,OIL(25X52X7)

€ 8.00

33

0930021001
ref: 33
O.D=30 (1.18) I.D=21 (0.83) W=13 (0.51)

BUSHING

€ 13.50

34

0938017001
ref: 34

CIRCLIP

€ 2.00

35

0938022001
ref: 35

CIRCLIP

€ 2.00

36

0939052001
ref: 36

C-RING

€ 2.50

37

0212106121
ref: 37

CROSS HEAD SCREW

€ 3.00

38

0422104060
ref: 38

DOWEL PIN

€ 2.00
