Buy Suzuki T Parts Online


OPTIONAL: CLUTCH-FORK SPRING COVER BOOT-FUEL TANK CAP

T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT

Optional: clutch-fork spring cover boot-fuel tank cap diagram T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT

OPTIONAL: CLUTCH-FORK SPRING COVER BOOT-FUEL TANK CAP T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT
OPTIONAL: CLUTCH-FORK SPRING COVER BOOT-FUEL TANK CAP T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT
OPTIONAL: CLUTCH-FORK SPRING COVER BOOT-FUEL TANK CAP T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT
prices are in EUR
ref
part #
description
quantity
1
2141111700
ref: 1
CLUTCH SLEEVE HUB
€ 0.00
2
2144111000
ref: 2
CLUTCH CORK PLATE
2144111000
€ 15.50
3
2145111000
ref: 3
CLUTCH STEEL PLATE
€ 0.00
4
2145111700
ref: 4
CLUTCH STEEL PLATE
€ 0.00
5
2531011701
ref: 5
THIS PART ALLOWS TRANSMISSION GEARS TO BE SHIFTED FROM 2ND DIRECTLY TO LOW PAST NEUTRAL
GEAR SHIFTING CAM COMP
€ 94.00
6
2534211700
ref: 6
FOR CHANGING TRANSMISSION TO 5 SPEEDS
GEAR SHIFTING CAM RETAINER
€ 0.00
7
3000011804
ref: 7
KEY LOCK TYPE
FUEL TANK CAP
€ 69.50
7
3000007829
ref: 7
KEY LOCK TYPE
FUEL TANK CAP
€ 0.00
8
5157111010
ref: 8
BOOT,SPRING COVER
5157111010
€ 36.50
9
5157311010
ref: 9
BAND,FRONT FORK COVER
5157311010
€ 4.50
10
6331011000
ref: 10
REAR FENDER EXTENSION
€ 0.00
11
0111106101
ref: 11
HEXAGON BOLT
€ 2.00
12
0832121061
ref: 12
LOCK WASHER
€ 2.50
13
0832221061
ref: 13
FLAT WASHER
€ 2.00
