prices are in EUR
ref
part #
description
quantity
1
1130011813
ref: 1
INCLUDES REF.NOS. 4,5,19-22,24-31
CRANKCASE ASS'Y
2
PLUG,TRANSMISSION BREATHER
3
ENGINE FRONT MOUNTING BOLT
5
BOLT 8X110
7
BOLT 10X215
8
NUT
9
NUT
10
0916808003
ref: 10
O.D=14 (0.55) I.D=8 (0.31) T=1.0 (0.04)
GASKET
11
0916810002
ref: 11
O.D=14.2 (0.56) I.D=10.1 (0.04)
GASKET(10X14X3.6) (NAS)
12
GASKET(14X19.2X2) (NAS)
13
0918008006
ref: 13
O.D=16 (0.63) I.D=8.7 (0.34) L=168 (6.61)
NO PRODUCT DESCRIPTION AVAILABLE
14
0918010002
ref: 14
O.D=22 (0.87) I.D=10.5 (0.41) W=30.4 (1.20)
SPACER
15
PLUG
16
PLUG(MAGNETO)
18
0928022001
ref: 18
O.D=26.6 (1.05) I.D=21.8 (0.86) T=2.4 (0.09)
O RING(D:2.4,ID:21.8)
23
SMALL HEAD HEXAGON BOLT
24
STRONG SMALL HEAD HEXAGON BOLT
25
STRONG SMALL HEAD HEXAGON BOLT
26
STRONG SMALL HEAD HEXAGON BOLT
