TOOL KIT

T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT

Tool kit diagram T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT

TOOL KIT T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT
TOOL KIT T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT
TOOL KIT T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT
prices are in EUR
ref
part #
description
quantity
1
0980111826
ref: 1
TOOL ASSY
€ 43.50
2
0981100010
ref: 2
TOOL BAG
€ 0.00
3
0981200001
ref: 3
COMBINATION PLIERS
€ 0.00
4
0981300001
ref: 4
8X9MM OPEN END WRENCH
€ 0.00
5
0981300006
ref: 5
10X12MM OPEN END WRENCH
€ 0.00
6
0981300009
ref: 6
14X17MM OPEN END WRENCH
€ 0.00
7
0981300012
ref: 7
POINT WRENCH
€ 22.50
8
0981400001
ref: 8
COMBINATION SCREW DRIVER
€ 0.00
9
0981400004
ref: 9
CROSS SCREW DRIVER
€ 0.00
10
0981400007
ref: 10
GRIP, SCREW DRIVER R,J,K,L,M
€ 0.00
11
0981600004
ref: 11
14MM BOX WRENCH
€ 0.00
12
0981600007
ref: 12
21MM BOX WRENCH
€ 0.00
13
0981700003
ref: 13
23MM OFFSET WRENCH
€ 0.00
14
0981700004
ref: 14
32MM OFFSET WRENCH
0981700004
€ 10.00
15
0981700005
ref: 15
WRENCH HANDLE
€ 0.00
16
0981800001
ref: 16
CONTACT POINT FILE
€ 1.50
