ref
part #
description
quantity
2
PISTON
2
PISTON 0.50
2
PISTON SET(OS:1.0)
3
RING SET,PISTON
3
RING SET,PISTON
3
RING SET,PISTON
4
1215111000
ref: 4
O.D=14 (0.55) I.D=9.4 (0.37) L=44.5 (1.75)
PIN,PISTON
5
CONNECTING ROD
6
PIN,CRANK
8
NO PRODUCT DESCRIPTION AVAILABLE
12
CRANKSHAFT OIL SEAL POSITIONING PIECE
13
CENTER CRANKSHAFT OIL SEAL POSITIONING PIECE
14
OIL GUIDE PLATE
16
0916020002
ref: 16
O.D=35 (1.38) I.D=20 (0.79) T.=1.0 (0.04)
CRANKSHAFT THRUST WASHER
18
0916020010
ref: 18
O.D.=34 (1.34) I.D=20 (0.79) T=1.0 (0.04)
WASHER (20X34X1)
19
0916614002
ref: 19
O.D=35 (1.38) I.D=14 (0.55) T=0.8 (0.03)
PRIMARY PINION WASHER
20
0918020013
ref: 20
O.D=26 (1.02) I.D=20 (0.79) W=11 (0.43)
PRIMARY DRIVE GEAR SPACER
21
ROLLER(4X13.8)
22
0926220014
ref: 22
O.D=55 (2.17) I.D=20 (0.79) W=15 (0.59)
BALL BEARING
23
0926225004
ref: 23
O.D=55 (2.17)I.D=25 (0.98) W=15 (0.59)
CENTER CRANKSHAFT BEARING
24
0926314001
ref: 24
O.D=18 (0.71) I.D=14 (0.55) W=17 (0.67)
BEARING
25
0926320001
ref: 25
O.D=26 (1.02) I.D=20 (0.79) W=17 (0.67)
BEARING
26
0928320009
ref: 26
O.D=55 (2.17) I.D=20 (0.79) W=7.5 (0.30)
OIL SEAL
27
0928325007
ref: 27
O.D=55 (2.17) I.D=25 (0.98) W=7.5 (0.30)
OIL SEAL CENTER
28
0928326004
ref: 28
O.D=55 (2.17) I.D=26 (1.02) W=7.5 (0.30)
SEAL,OIL
29
RING,SNAP 14MM
30
RIGHT CRANKSHAFT BEARING POSITION PIECE
33
KEY
