Buy Suzuki T Parts Online


T20 HEAD LAMP-DUAL SEAT NORWAY

T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT

T20 head lamp-dual seat norway diagram T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT

T20 HEAD LAMP-DUAL SEAT NORWAY T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT
T20 HEAD LAMP-DUAL SEAT NORWAY T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT
T20 HEAD LAMP-DUAL SEAT NORWAY T20 TC250 SCRAMBLER 1965-1969 GENERAL EXPORT
prices are in EUR
ref
part #
description
quantity
1
3510011660
ref: 1
E16
HEAD LAMP ASS'Y
€ 0.00
2
3511111030
ref: 2
E16
HEAD LAMP RIM
3511111030
€ 27.50
3
3512211660
ref: 3
E16
12V 35/35W
HEAD LAMP BULB
€ 108.50
4
3512311660
ref: 4
E16
HEAD LAMP REFLECTOR
€ 0.00
5
3512411660
ref: 5
E16
HEAD LAMP LENS
€ 0.00
6
3512511030
ref: 6
E16
HEAD LAMP LENS GASKET
€ 0.00
7
3512811030
ref: 7
E16
SPRING,HEAD LA
3512811030
€ 2.50
8
3517111660
ref: 8
E16
HEAD LAMP BULB SOCKET
€ 0.00
9
3517211660
ref: 9
E16
HEAD LAMP SOCKET RUBBER CAP
€ 0.00
10
3518911030
ref: 10
E16
HEAD LAMP RIM FITTING SPACER
€ 0.00
11
4510011611
ref: 11
E16
DUAL SEAT ASS'Y
€ 0.00
12
4518011610
ref: 12
E16
DUAL SEAT PASSENGER STRAP
€ 0.00
13
5110011011019
ref: 13
E16
FRONT FORK ASS'Y
€ 0.00
13
5110011011078
ref: 13
E16
FRONT FORK ASS'Y
€ 0.00
13
5110011011079
ref: 13
E16
FRONT FORK ASS'Y
€ 0.00
14
5117111010
ref: 14
E16
SPRING,FRONT FORK
€ 17.00
15
5157111010
ref: 15
E16
BOOT,SPRING COVER
5157111010
€ 36.50
16
5157311010
ref: 16
E16
BAND,FRONT FORK COVER
5157311010
€ 4.50
17
5181011001019
ref: 17
E16
HEAD LAMP HOUSING
€ 0.00
17
5181011001078
ref: 17
E16
HEAD LAMP HOUSING
€ 0.00
17
5181011001079
ref: 17
E16
HEAD LAMP HOUSING
€ 0.00
18
0947112001
ref: 18
E16
12V 3W
BULB(12V3.4W,STANLEY,A72A)
0947112001
€ 1.50
