THROTTLE GRIP-BRAKE LEVER-CLUTCH LEVER-HANDLE SWITCH

ref

part #

description

quantity

1

5710011011
ref: 1

THROTTLE GRIP ASS'Y

€ 55.50

2

5710011830
ref: 2

THROTTLE GRIP LOWER HOLDER ASS'Y

€ 0.00

3

5711011011
ref: 3

GRIP,THROTTLE

€ 22.50

4

5711111012
ref: 4

GRIP

€ 22.50

5

5712111010
ref: 5

THROTTLE GRIP UPPER HOLDER

€ 5.00

6

5717011010
ref: 6

THROTTLE GRIP ADJUSTER

€ 2.50

7

5721111011
ref: 7

GRIP,LEFT

€ 30.00

8

5730011010
ref: 8

LEVER ASSEMBLY,BRAKE

€ 47.00

9

5742011010
ref: 9

LEVER,BRAKE

€ 30.50

10

5743111010
ref: 10

BOLT,LEVER

€ 6.00

11

5743311010
ref: 11

NUT,LEVER FITTNG

€ 5.50

12

5744111010
ref: 12

ADJUSTER,CABLE

€ 8.00

13

5744211010
ref: 13

NUT,CABLE ADJUSTER

€ 4.00

14

5745111010
ref: 14
O.D=6 (0.24) L=20 (0.79)

LEVER HOLDER FITTING BOLT

€ 2.00

15

5750011010
ref: 15

LEVER ASSEMBLY,CLUTCH

€ 45.00

16

5762011010
ref: 16

LEVER,CLUTCH

€ 35.00

17

5770011630
ref: 17

SWITCH ASSEMBLY,HANDLE

€ 31.50

17

5770011600
ref: 17
T20-49661

SWITCH ASSEMBLY,HANDLE

€ 31.50

18

5770111630
ref: 18

HANDLE SWITCH UPPER COVER ASS'Y

€ 0.00

18

5770111600
ref: 18
T20-49661

HANDLE SWITCH UPPER COVER ASS'Y

€ 0.00

19

5770211010
ref: 19

HANDLE SWITCH LOWER COVER ASS'Y

€ 0.00

20

5772011630
ref: 20

WIRING HARNESS, SWITCH

€ 59.00

20

5772011600
ref: 20
T20-49661

WIRING HARNESS, SWITCH

€ 59.00

21

5773309600
ref: 21

HANDLE SWITCH UPPER COVER RUBBER

€ 3.50

22

5775011010
ref: 22

BUTTON, HORN

€ 1.50

23

5776111010
ref: 23

HORN BUTTON SPRING

€ 2.00

24

0211103061
ref: 24

CROSS HEAD SCREW

€ 1.00

25

0211105201
ref: 25

CROSS HEAD SCREW

€ 3.00

26

0212103081
ref: 26

CROSS HEAD SCREW

€ 1.00

27

0411116151
ref: 27

COTTER PIN

€ 2.00

28

0831111051
ref: 28

HEXAGON NUT

€ 1.00

29

0832121031
ref: 29

LOCK WASHER

€ 1.50

30

0832121061
ref: 30

LOCK WASHER

€ 2.50

all assemblies
