CAM CHAIN

GW250 INAZUMA 2014 (L4) USA (E03)

Cam chain diagram GW250 INAZUMA 2014 (L4) USA (E03)

CAM CHAIN GW250 INAZUMA 2014 (L4) USA (E03)

CAM CHAIN GW250 INAZUMA 2014 (L4) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

1276048H10
ref: 1

CHAIN,CAMSHAFT DRIVE

€ 73.00

2

1277148H00
ref: 2

GUIDE,CAM CHAIN

€ 20.00

3

1281048H00
ref: 3

TENSIONER,CAM CHAIN

€ 9.50

4

015470612A
ref: 4

BOLT

€ 2.00

5

1283002A10
ref: 5

ADJUSTER ASSY,TENSIONER

€ 10.50

6

1283748H00
ref: 6

GASKET,TENSIONER ADJUSTER(NA) (NAS)

€ 2.50

7

015470620A
ref: 7

BOLT

€ 2.50
