CRANKCASE COVER
GW250 INAZUMA 2014 (L4) USA (E03)
Crankcase cover diagram GW250 INAZUMA 2014 (L4) USA (E03)
CRANKCASE COVER GW250 INAZUMA 2014 (L4) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1134048H00
ref: 1
COVER,CLUTCH
€ 100.00
2
1197148H00
ref: 2
LENS,OIL LEVEL CHECK
€ 4.00
3
1148248H00
ref: 3
GASKET,CLUTCH COVER (NAS)
€ 25.00
4
015470630A
ref: 4
BOLT
€ 2.50
5
0421109149
ref: 5
PIN
€ 2.00
6
1197248H00
ref: 6
PLUG,OIL FILLER
€ 2.50
7
0928017003
ref: 7
O RING(D:3.1,ID:16.8)
€ 2.00
8
1135148H00
ref: 8
COVER,MAGNETO
€ 87.00
9
1148348H00
ref: 9
GASKET,MAGNETO COVER (NAS)
€ 12.00
10
015470635A
ref: 10
BOLT
€ 3.00
11
0421109149
ref: 11
PIN
€ 2.00
12
1135248H00
ref: 12
GASKET,TDC PLUG (NAS)
€ 1.50
13
0924712104
ref: 13
PLUG,12X9
€ 2.50
14
092593601620H
ref: 14
PLUG(SILVER)
€ 10.50
15
0928033004
ref: 15
O RING(D:3.1,ID:32.7)
€ 2.50
16
1136048H00
ref: 16
COVER,ENGINE SPROCKET
€ 33.00
17
015470625A
ref: 17
BOLT
€ 2.50
18
1137148H00
ref: 18
BRACKET,SPEED SENSOR
€ 31.00
19
015470640A
ref: 19
BOLT
€ 2.50
20
0421109149
ref: 20
PIN
€ 2.00
