TURN SIGNAL LAMP (E1,E24)

ref

part #

description

quantity

1

3560106B00
ref: 1

LAMP ASSY, FRONT TURN SIGNAL

€ 88.50

2

3561227A00
ref: 2

LENS

€ 11.50

3

3561327A00
ref: 3

GASKET (NAS)

€ 3.00

4

3562327A00
ref: 4

SCREW(3X30)

€ 1.50

5

3572540511
ref: 5

SCREW

€ 1.50

6

3562727A02
ref: 6

GASKET (NAS)

€ 1.50

7

0347112006
ref: 7

BULB (12V,23W)

€ 0.00

8

3567427A00
ref: 8

GROMMET

€ 13.50

9

0831626105
ref: 9

NUT

€ 3.50

10

3560328A00
ref: 10

LAMP ASSY, READ TURN SIGNAL

€ 88.50

11

3561227A00
ref: 11

LENS

€ 11.50

12

3561327A00
ref: 12

GASKET (NAS)

€ 3.00

13

3562327A00
ref: 13

SCREW(3X30)

€ 1.50

14

3572540511
ref: 14

SCREW

€ 1.50

15

3562727A02
ref: 15

GASKET (NAS)

€ 1.50

16

0947112006
ref: 16

BULB(12V23W,STANLEY,A4577A)

€ 4.00

17

3569206B00
ref: 17

CUSHION

€ 4.50

18

3569506B00
ref: 18

SPACER

€ 4.50

19

0916010078
ref: 19

WASHER (10.2X27X1.6)

€ 2.00

20

0831626105
ref: 20

NUT

€ 3.50

21

3061031310
ref: 21

RELAY, TURN SIGNAL

€ 0.00

all assemblies
