RIGHT HANDLE LEVER

ref

part #

description

quantity

1-1

5711012D00
ref: 1-1
MODEL M/N

GRIP,THROTTLE

€ 26.50

1-2

5711012D11
ref: 1-2
MODEL P/R/S/T

GRIP,THROTTLE

€ 25.50

2

5710028B00
ref: 2
MODEL M/N

CASE ASSEMBLY,THROTTLE

€ 34.00

3

5712913601
ref: 3
MODEL M/N

COVER,THROTTLE CASE

€ 7.00

4

0213204105
ref: 4
MODEL M/N

SCREW 4X10

€ 2.50

5

0211205164
ref: 5
MODEL M/N

SCREW

€ 2.00

6

5710014D00
ref: 6
MODEL P/R/S/T

CASE ASSY,THROTTLE

€ 24.00

7

0912505066
ref: 7
MODEL P/R/S/T

SCREW(5X25)

€ 2.00

8

0211205205
ref: 8
MODEL P/R/S/T

SCREW 5X20

€ 2.50

9

5742113001
ref: 9

LEVER,BRAKE

€ 18.00

10

5743105D00
ref: 10

BOLT,BRAKE LEVER PIVOT

€ 9.00

11

0831921065
ref: 11

NUT

€ 2.50

12

5746017C00
ref: 12

SWITCH ASSEMBLY,STOP

€ 32.50

13

5746517C00
ref: 13

SCREW

€ 1.50

14

0940712402
ref: 14

CLAMP(L:120)

€ 3.00

15-1

5734105D0012F
ref: 15-1
MODEL M/N

COVER,KNUCKLE,R

€ 61.00

15-2

5734105D0022P
ref: 15-2
MODEL M

COVER,KNUCKLE,R

€ 62.50

15-3

5734105D001MW
ref: 15-3
MODEL N

COVER,KNUCKLE,R

€ 57.00

15-4

5734105D001AY
ref: 15-4
MODEL P FOR 12F

COVER,KNUCKLE RH (BLUE)

€ 27.00

15-5

5734105D0021C
ref: 15-5
MODEL P/R/S FOR 33J

COVER,KNUCKLE,R

€ 21.00

15-6

5734105D000NF
ref: 15-6
MODEL R/S FOR 1LE

COVER,KNUCKLE,R

€ 28.00

15-7

5734105D00019
ref: 15-7
MODEL T

COVER,KNUCKLE,RIGHT

€ 21.00

16-1

0912505042
ref: 16-1
MODEL M/N/P

SCREW(5X10)

€ 2.50

16-2

0214205107
ref: 16-2
MODEL R/S/T

SCREW

€ 2.50

17

0916005017
ref: 17

WASHER (5.5X16X1.2)

€ 2.50

18

0916006042
ref: 18

WASHER (6.5X17X1.6)

€ 2.00

19

0831921068
ref: 19

NUT 6MM

€ 2.00
