FRAME HEAD COVER

VLR1800T BOULEVARD C109R 2008 (K8) USA CALIFORNIA (E03 E33)

Frame head cover diagram VLR1800T BOULEVARD C109R 2008 (K8) USA CALIFORNIA (E03 E33)

FRAME HEAD COVER VLR1800T BOULEVARD C109R 2008 (K8) USA CALIFORNIA (E03 E33)

FRAME HEAD COVER VLR1800T BOULEVARD C109R 2008 (K8) USA CALIFORNIA (E03 E33)

prices are in EUR

ref

part #

description

quantity

1

4735122H00019
ref: 1

COVER,FRAME HEAD,R(BLACK)

€ 135.50

2

4736122H00019
ref: 2

COVER,FRAME HEAD,L(BLACK)

€ 135.50

3

0932008018
ref: 3

CUSHION

€ 4.00

4

0932008029
ref: 4

CUSHION

€ 2.50

5

0940906329
ref: 5

CLIP

€ 3.00

6

0913906131
ref: 6

SCREW(6X16)

€ 4.00

7

4737022H00
ref: 7

PLATE,FRAME HEAD COVER,R

€ 23.50

8

4738022H00
ref: 8

PLATE,FRAME HEAD COVER,L

€ 19.00

9

015500616A
ref: 9

BOLT

€ 2.50

10

4735222H00
ref: 10

CUSHION,HEAD COVER,R

€ 34.50

11

4736222H00
ref: 11

CUSHION,HEAD COVER,L

€ 34.50
