HANDLE SWITCH

VLR1800T BOULEVARD C109R 2008 (K8) USA CALIFORNIA (E03 E33)

Handle switch diagram VLR1800T BOULEVARD C109R 2008 (K8) USA CALIFORNIA (E03 E33)

HANDLE SWITCH VLR1800T BOULEVARD C109R 2008 (K8) USA CALIFORNIA (E03 E33)

HANDLE SWITCH VLR1800T BOULEVARD C109R 2008 (K8) USA CALIFORNIA (E03 E33)

prices are in EUR

ref

part #

description

quantity

1

3720041FC1
ref: 1

STUURSCHAK.RH

€ 238.50

2

021120545B
ref: 2

SCREW

€ 4.00

3

021120510B
ref: 3

SCREW

€ 2.00

4

021120535B
ref: 4

SCREW

€ 1.50

5

0940714407
ref: 5

CLAMP(L:145)

€ 4.00

6

3740041FC0
ref: 6

SWITCH ASSY,HANDLE,L

€ 331.00

7

021120545B
ref: 7

SCREW

€ 4.00

8

021120530B
ref: 8

SCREW

€ 1.50

9

0940714407
ref: 9

CLAMP(L:145)

€ 4.00
