FRAME

DL650A VSTROM 2012 (L2) USA (E03)

Frame diagram DL650A VSTROM 2012 (L2) USA (E03)

FRAME DL650A VSTROM 2012 (L2) USA (E03)

FRAME DL650A VSTROM 2012 (L2) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

4110027G21YAP
ref: 1

FRAME

€ 3,716.50

2

4120011J00
ref: 2

RAIL,SEAT

€ 650.00

3

0910310379
ref: 3

BOLT(10X30)

€ 4.00

4

4191106G90YAP
ref: 4

BRACKET,ENGINE MOUNTING,R

€ 457.50

5

4191206G90YAP
ref: 5

BRACKET,ENGINE MOUNTING,L

€ 456.50

6

0910608121
ref: 6

BOLT(8X30)

€ 3.50

7

4192316G00
ref: 7

BOLT,CRANK CASE ADJUST CTR

€ 19.00

8

4192219F20
ref: 8

NUT,CRANK CASE ADJUST CTR

€ 12.00

9

4192116G00
ref: 9

BOLT,CASE LWR & RR HEAD ADJ

€ 10.50

10

4192233E20
ref: 10

NUT,CRANK CASE ADJUST LWR

€ 10.50

11

4194119F01
ref: 11

SPACER,MOUNTING RR UPR,R

€ 25.00

12

0910608168
ref: 12

BOLT(8X38)

€ 2.50

13

4358527G10
ref: 13

COVER,PIVOT,R

€ 10.50

14

4359527G00
ref: 14

COVER,PIVOT,L

€ 13.00

15

0925104003
ref: 15

CAP

€ 2.00
