STARTER CLUTCH

DL650A VSTROM 2012 (L2) USA (E03)

Starter clutch diagram DL650A VSTROM 2012 (L2) USA (E03)

STARTER CLUTCH DL650A VSTROM 2012 (L2) USA (E03)
STARTER CLUTCH DL650A VSTROM 2012 (L2) USA (E03)
STARTER CLUTCH DL650A VSTROM 2012 (L2) USA (E03)
prices are in EUR
ref
part #
description
quantity
1
1261127G00
ref: 1
GEAR,STARTER IDLE
1261127G00
€ 57.50
2
0920612006
ref: 2
PIN(8X12X45.5)
0920612006
€ 7.50
3
1260006821
ref: 3
CLUTCH SET,STARTER
1260006821
€ 263.00
4
0913908023
ref: 4
SCREW(8X16)
€ 2.50
