AIR CLEANER

A100 AS100 AC100 1969 USA (E03)

Air cleaner diagram A100 AS100 AC100 1969 USA (E03)

AIR CLEANER A100 AS100 AC100 1969 USA (E03)

AIR CLEANER A100 AS100 AC100 1969 USA (E03)

prices are in EUR

ref

part #

description

quantity

2

1144012002
ref: 2

COVER,CARBURETOR TOP

€ 20.00

5

1372112020
ref: 5

PIPE,AIR CLEANER INLET

€ 18.50

7

1378012021
ref: 7

FILTER ASSY

€ 23.50

9

0211204163
ref: 9

SCREW 4X16

€ 1.00

11

0211205167
ref: 11

SCREW

€ 2.50

12

0832101057
ref: 12

WASHER,LOCK

€ 2.00

13

0832201057
ref: 13

WASHER

€ 2.50

14

0912505102
ref: 14

SCREW(5X14)

€ 2.50

14-1

0912505002
ref: 14-1

CARBORATOR COVER SCREW

€ 0.00

15

0925014002
ref: 15

Plug

€ 4.50

16

0930904001
ref: 16

GROMMET

€ 4.00

17

0930904004
ref: 17

GROMMET

€ 3.50
