FRAME-DUAL SEAT-FRAME COVER-REAR FENDER

A100 AS100 AC100 1969 USA (E03)

Frame-dual seat-frame cover-rear fender diagram A100 AS100 AC100 1969 USA (E03)

FRAME-DUAL SEAT-FRAME COVER-REAR FENDER A100 AS100 AC100 1969 USA (E03)

FRAME-DUAL SEAT-FRAME COVER-REAR FENDER A100 AS100 AC100 1969 USA (E03)

prices are in EUR

ref

part #

description

quantity

14

0150005103
ref: 14

BOLT

€ 1.50

15

0150008207
ref: 15

BOLT

€ 3.00

16

0120406127
ref: 16

BOLT

€ 1.50

18

0831000033
ref: 18

NUT

€ 2.00

19

0831000067
ref: 19

NUT

€ 2.50

20

0832101057
ref: 20

WASHER,LOCK

€ 2.00

21

0832101067
ref: 21

WASHER,LOCK

€ 2.50

22

0832101087
ref: 22

WASHER,LOCK

€ 2.00

23

0832201067
ref: 23

WASHER

€ 2.00

24

0832201087
ref: 24

WASHER

€ 2.00

25

0915206002
ref: 25

NUT

€ 2.00

27

0916006084
ref: 27

WASHER(6.5X18X1.6)

€ 2.00

32

0932110002
ref: 32

CUSHION(11.5X22X20)

€ 2.00

33

0938506004
ref: 33

CLIP

€ 11.00
