STAND-BRAKE PEDAL-BRAKE ROD-FOOTREST BAR

A100 AS100 AC100 1969 USA (E03)

Stand-brake pedal-brake rod-footrest bar diagram A100 AS100 AC100 1969 USA (E03)

STAND-BRAKE PEDAL-BRAKE ROD-FOOTREST BAR A100 AS100 AC100 1969 USA (E03)

STAND-BRAKE PEDAL-BRAKE ROD-FOOTREST BAR A100 AS100 AC100 1969 USA (E03)

prices are in EUR

ref

part #

description

quantity

2

4221103001
ref: 2

SPACER

€ 4.50

8

4322103001
ref: 8

STOPPER,BRAKE PEDAL

€ 6.00

13

0150008163
ref: 13

BOLT

€ 2.00

15

0832101087
ref: 15

WASHER,LOCK

€ 2.00

16

0832201057
ref: 16

WASHER

€ 2.50

17

0832201087
ref: 17

WASHER

€ 2.00

18

09150C05101J000
ref: 18

BRAKE ROD ADJ N

09150C05101J000

€ 20.00

18-1

0915005001
ref: 18-1

NUT

€ 3.50

19

0916022033
ref: 19

WASHER(22.5X38X1)

€ 3.50

20

0920008002
ref: 20

PIN

€ 2.00

21

09209C10001J000
ref: 21

BRAKE ROD LEVER

09209C10001J000

€ 4.50

22

0944009004
ref: 22

SPRING

€ 2.00

23

0944316007
ref: 23

SPRING

€ 12.00
