CLUTCH

A100 AS100 AC100 1969 USA (E03)

Clutch diagram A100 AS100 AC100 1969 USA (E03)

CLUTCH A100 AS100 AC100 1969 USA (E03)

CLUTCH A100 AS100 AC100 1969 USA (E03)

prices are in EUR

ref

part #

description

quantity

3

2144142G00
ref: 3

PLATE,CLUTCH DRIVE (NAS)

€ 12.00

4

2145103000
ref: 4

PLATE,CLUTCH DRIVEN

€ 9.50

6

2311112000
ref: 6

ROD,CLUTCH PUSH

€ 6.50

8

2320005030
ref: 8

SCREW ASSY,CLUTCH RELEASE

€ 25.00

9

2322207000
ref: 9

PIECE,RELEASE ARM END

€ 5.00

11

0831000067
ref: 11

NUT

€ 2.50

12

0913406010
ref: 12

SCREW(6X25)

€ 3.00

13

0914016001
ref: 13

NUT

€ 4.50

14

0916717002
ref: 14

WASHER,LOCK

€ 2.00

15

0918017011
ref: 15

SPACER (17X21X52)

€ 14.50

17

0926102001
ref: 17

PIN(2.5X19.8)

€ 1.50

18

0944308001
ref: 18

SPRING

€ 3.00
