CLUTCH

VZ800 BOULEVARD M50 2005 (K5) USA (E03) BOULEVARDM50 BOULEVARD-M

Clutch diagram VZ800 BOULEVARD M50 2005 (K5) USA (E03) BOULEVARDM50 BOULEVARD-M

CLUTCH VZ800 BOULEVARD M50 2005 (K5) USA (E03) BOULEVARDM50 BOULEVARD-M
CLUTCH VZ800 BOULEVARD M50 2005 (K5) USA (E03) BOULEVARDM50 BOULEVARD-M
CLUTCH VZ800 BOULEVARD M50 2005 (K5) USA (E03) BOULEVARDM50 BOULEVARD-M
prices are in EUR
ref
part #
description
quantity
1
2120038840
ref: 1
GEAR ASSY,PRIMARY(NT:71)
2120038840
€ 321.00
2
0918025077
ref: 2
SPACER(25X38X6.5)
0918025077
€ 7.50
3
0916025055
ref: 3
WASHER(25X50X2.5)
0916025055
€ 9.50
4
0926335017
ref: 4
BEARING(35X40X35.8)
0926335017
€ 36.50
5
2141041F00
ref: 5
HUB,CLUTCH SLEEVE
2141041F00
€ 95.50
6
2147137400
ref: 6
SEAT,WAVE WASHER(T:1.4)
2147137400
€ 8.00
7
0916422007
ref: 7
WASHER
0916422007
€ 5.00
8
0914022008
ref: 8
NUT
0914022008
€ 4.50
9
0916400004
ref: 9
WASHER
0916400004
€ 9.00
10
0916025055
ref: 10
WASHER(25X50X2.5)
0916025055
€ 9.50
11
2144137400
ref: 11
PLATE,CLUTCH DRIVE (NAS)
2144137400
€ 20.50
12
2144237401
ref: 12
PLATE,CLUTCH DRIVE(T:3.5) (NAS)
2144237401
€ 11.50
13
2145114A00
ref: 13
PLATE,CLUTCH DRIVEN(T:1.6) (NAS)
2145114A00
€ 6.50
14
2146227A00
ref: 14
DISC,CLUTCH PRESSURE
2146227A00
€ 37.00
15
2141341F00
ref: 15
SPRING,CLUTCH
€ 5.50
16
0911606203
ref: 16
BOLT(6X30)
0911606203
€ 2.50
17
2312131E00
ref: 17
PIECE,CLUTCH PUSH
2312131E00
€ 18.50
18
0926315003
ref: 18
BEARING(15X28X2)
0926315003
€ 7.00
19
0916015045
ref: 19
WASHER(15.5X28X1)
0916015045
€ 4.00
20
2311027A00
ref: 20
ROD,CLUTCH
2311027A00
€ 17.00
21
2311145C00
ref: 21
ROD,CLUTCH PUSH,L
2311145C00
€ 11.00
22-1
0928506017
ref: 22-1
SEAL,OIL(6X34X11)
0928506017
€ 11.00
22-2
0928306010
ref: 22-2
SEAL,OIL(6X34X10.5)
0928306010
€ 14.00
23
2311745C00
ref: 23
RETAINER,CL PUSH ROD OIL SEAL
2311745C00
€ 4.50
24
2313045C00
ref: 24
PLATE,CLUTCH RELEASE SCREW
2313045C00
€ 16.50
25
2320041F00
ref: 25
SCREW ASSY,CLUTCH RELEASE
2320041F00
€ 62.00
26
0913406010
ref: 26
SCREW(6X25)
0913406010
€ 3.00
27
0831000067
ref: 27
NUT
0831000067
€ 2.50
28
0944309050
ref: 28
SPRING
0944309050
€ 3.00
29
071200620B
ref: 29
BOLT
071200620B
€ 3.50
30
071200616B
ref: 30
BOLT
071200616B
€ 2.50
