GEAR SHIFTING

XF650 1998 (W) (E02 E04 E17 E18 E22 E24 E25 E34) / P9

Gear shifting diagram XF650 1998 (W) (E02 E04 E17 E18 E22 E24 E25 E34) / P9

GEAR SHIFTING XF650 1998 (W) (E02 E04 E17 E18 E22 E24 E25 E34) / P9
GEAR SHIFTING XF650 1998 (W) (E02 E04 E17 E18 E22 E24 E25 E34) / P9
GEAR SHIFTING XF650 1998 (W) (E02 E04 E17 E18 E22 E24 E25 E34) / P9
prices are in EUR
ref
part #
description
quantity
1
2521137401
ref: 1
FORK,GEAR SHIFT NO.1
2521137401
€ 58.50
2
2522137401
ref: 2
FORK,GEAR SHIFT NO.2
2522137401
€ 58.50
3
2523114A01
ref: 3
FORK,GEAR SHIFT NO.3
2523114A01
€ 54.50
4
2541120A11
ref: 4
L:95
SHAFT,GEAR SHIFT FORK
2541120A11
€ 14.50
5
2542114A02
ref: 5
L:75
SHAFT,GEAR SHIFT FORK
2542114A02
€ 14.50
6
2531037400
ref: 6
CAM,GEAR SHIFT
2531037400
€ 91.50
7
2532231310
ref: 7
<-25322-31302
GEAR,GEAR SHIFT CAM DRIVEN
2532231310
€ 14.50
8
2532334201
ref: 8
PAWL,GEAR SHIFT NO.1
2532334201
€ 6.00
9
2532434201
ref: 9
PAWL,GEAR SHIFT NO.2
2532434201
€ 6.00
10
0926105003
ref: 10
PIN(5X8)
0926105003
€ 1.50
11
0944004003
ref: 11
SPRING
0944004003
€ 1.50
12
2533114A00
ref: 12
LIFTER,GEAR SHAFT PAWL
2533114A00
€ 6.00
13
0212206123
ref: 13
SCREW
0212206123
€ 3.00
14
2534140001
ref: 14
STOPPER,GEAR SHIFT POLE
2534140001
€ 6.50
15
0212206123
ref: 15
SCREW
0212206123
€ 3.00
16
2535037400
ref: 16
STOPPER,GEAR SHIFT CAM
2535037400
€ 8.00
17
0911106054
ref: 17
BOLT(6X14.6)
0911106054
€ 1.50
18
0821106141
ref: 18
WASHER
0821106141
€ 2.50
19
0944308020
ref: 19
SPRING
0944308020
€ 2.00
20
0922304001
ref: 20
RIVET
0922304001
€ 1.50
21
2538137401
ref: 21
PLATE,GEAR SHIFT CAM STOPPER
2538137401
€ 10.50
22
0422104069
ref: 22
PIN
0422104069
€ 2.00
23
2551032E00
ref: 23
SHAFT,GEAR SHIFT
2551032E00
€ 64.00
24
0944426023
ref: 24
SPRING
0944426023
€ 3.00
25
2567101000
ref: 25
STOPPER,GEAR SHIFT CAM
2567101000
€ 3.00
26
0928512002
ref: 26
OIL SEAL
0928512002
€ 7.00
27
0821212201
ref: 27
WASHER
€ 1.50
28
0833131126
ref: 28
CIRCLIP,12 MM
0833131126
€ 2.00
29
2560032E10
ref: 29
LEVER ASSY,GEAR SHIFT
2560032E10
€ 174.50
30
2565203D00
ref: 30
RUBBER,GEAR SHIFT PEDAL
2565203D00
€ 3.50
31
0150006203
ref: 31
BOLT
0150006203
€ 2.00
32
3772032E00
ref: 32
BASE ASSY,GEAR SHIFT TERMINAL
3772032E00
€ 60.50
33
0211205163
ref: 33
SCREW
0211205163
€ 2.00
34
0920905011
ref: 34
PIN(5X15.5)
0920905011
€ 2.00
35
0944004010
ref: 35
SPRING
0944004010
€ 1.50
