FRONT DAMPER (MODEL D)

ref

part #

description

quantity

0

5110349330
ref: 0

DAMPER ASSY, RH

€ 818.50

0

5110449330
ref: 0

DAMPER ASSY, LH

€ 818.50

1

511304933015T
ref: 1

TUBE,FORK,OUTER,RIGHT

€ 201.50

2

511404933015T
ref: 2

TUBE,OUTER,LEFT

€ 234.50

3

5115640301
ref: 3

RING,STOPPER

€ 4.50

4

5115349001
ref: 4

OIL SEAL,FRONT FORK

€ 16.50

5

0141108308
ref: 5

STUD 8X30

€ 2.00

6

5111049300
ref: 6

TUBE,INNER

€ 294.50

7

5112149200
ref: 7

PISTON

€ 18.00

8

5117245110
ref: 8

PISTON,FREE

€ 10.50

9

5111745110
ref: 9

O-RING

€ 4.00

10

5135149200
ref: 10

CAP

€ 59.00

11

5118949300
ref: 11

CAP,RUBBER

€ 9.00

12

5114716510
ref: 12

BOLT,FORK CYLINDER(10X25)

€ 3.50

13

5114841310
ref: 13

GASKET (NAS)

€ 2.50

14

5119545420
ref: 14

PIECE,OIL LOCK

€ 15.50

15

5112345420
ref: 15

WASHER

€ 3.50

16

5112545420
ref: 16

SPRING,LEAF

€ 3.50

17

5114649300
ref: 17

CYLINDER,FRONT FORK

€ 118.00

18

5119649000
ref: 18

RING,PISTON

€ 9.00

19

5117749000
ref: 19

SPRING,REBOUND

€ 7.50

20

5117149310
ref: 20

SPRING,FRONT FORK

€ 74.50

21

5117349002
ref: 21

SEAL,DUST

€ 13.00

22

0211204088
ref: 22

SCREW

€ 1.50

23

5118303010
ref: 23

GASKET,DRAIN,PLUG (NAS)

€ 3.00

24

5113249500291
ref: 24

HOLDER,AXLE

€ 24.50

25

0831011085
ref: 25

NUT

€ 1.50

26

0832121088
ref: 26

LOCK WASHER

€ 2.00

27

0832221088
ref: 27

WASHER

€ 2.00

28

5179944130
ref: 28

O RING

€ 5.00

29

5179011330
ref: 29

PLANGER SET,MODULATOR

€ 122.00

30

5177045920
ref: 30

VALVE SET,MODULATOR

€ 94.50

31

5177844130
ref: 31

BREATHER,AIR

€ 12.50

32

5177944130
ref: 32

CAP,BREADER

€ 6.00

33

5175311330
ref: 33

BOLT, MODULATOR (5X12)

€ 2.50

34

5179644130
ref: 34

BOLT,FRONT FORK

€ 3.00

all assemblies
