STAND (E16, E18, E22, E25, E26)

GSX750S 1983 (D) (E01 E02 E04 E06 E18 E21 E22 E24 E25 E30 34 39)

Stand (e16, e18, e22, e25, e26) diagram GSX750S 1983 (D) (E01 E02 E04 E06 E18 E21 E22 E24 E25 E30 34 39)

STAND (E16, E18, E22, E25, E26) GSX750S 1983 (D) (E01 E02 E04 E06 E18 E21 E22 E24 E25 E30 34 39)

STAND (E16, E18, E22, E25, E26) GSX750S 1983 (D) (E01 E02 E04 E06 E18 E21 E22 E24 E25 E30 34 39)

prices are in EUR

ref

part #

description

quantity

1-1

4210049301
ref: 1-1
E16, E18

STAND,CENTER

€ 211.50

1-2

4210049311
ref: 1-2
E22, E25, E26

STAND, CENTER

€ 0.00

2

0918010040
ref: 2

SPACER(10X16X38.8)

€ 3.00

3

0910110018
ref: 3

BOLT

€ 5.50

4

0832121108
ref: 4

LOCK WASHER

€ 2.00

5

0938510001
ref: 5

CLIP

€ 1.50

6-1

0944320001
ref: 6-1
E16,E18

SPRING

€ 11.00

6-2

0944318003
ref: 6-2
E22,E25,E26

SPRING

€ 5.50

7

0932110001
ref: 7

CUSHION

€ 2.50

8

4231049310
ref: 8

STAND, PROP

€ 90.00

9

0944315013
ref: 9
E16,E18,E26

SPRING

€ 22.50

10

0944314019
ref: 10
E22,E25

SPRING

€ 7.00

11

0944322002
ref: 11
E22,E25

SPRING

€ 7.00

12

0911110024
ref: 12

BOLT(10X32)

€ 4.50

13

0831022108
ref: 13

NUT

€ 2.50

14-1

4311049301
ref: 14-1
MODEL Z

PEDAL, BRAKE

€ 70.50

14-2

4311149310
ref: 14-2
MODEL D

PEDAL,BRAKE

€ 54.00

15

4312049301
ref: 15

ARM,BRAKE PEDAL

€ 23.50

16-1

0120408257
ref: 16-1
MODEL Z

BOLT

€ 2.00

16-2

0110708308
ref: 16-2
MODEL D

BOLT (8X30)

€ 2.50

17

0832121088
ref: 17

LOCK WASHER

€ 2.00

18

0944312022
ref: 18

SPRING

€ 3.50

19

0920006037
ref: 19

PIN

€ 5.00

20

0411120158
ref: 20

PIN

€ 1.50

21

0832221068
ref: 21

WASHER

€ 2.00

22

0110706208
ref: 22

BOLT

€ 2.00

23

0831011068
ref: 23

NUT

€ 2.50
