HIGH SEAT (OPTIONAL)

DL1000A VSTROM 2014 (L4) USA (E03)

High seat (optional) diagram DL1000A VSTROM 2014 (L4) USA (E03)

HIGH SEAT (OPTIONAL) DL1000A VSTROM 2014 (L4) USA (E03)
HIGH SEAT (OPTIONAL) DL1000A VSTROM 2014 (L4) USA (E03)
HIGH SEAT (OPTIONAL) DL1000A VSTROM 2014 (L4) USA (E03)
prices are in EUR
ref
part #
description
quantity
1-1
4510031J60AR8
ref: 1-1
High Seat, Black/Gray
4510031J60AR8
€ 222.50
1-2
4510031J60AT3
ref: 1-2
SEAT ASSY,HIGH
4510031J60AT3
€ 225.00
